Metal Engraving Milling CNC Router High Precision

  • Metal Engraving Milling CNC Router High Precision
  • Smartech
  • 1700 * 1800 * 1850mm
  • 3.2kw
  • red
Product Overview

Application of cnc moulding machine

1.It is suitable for engraving,moulding and drilling compactly all sorts of materials such as steel,copper,aluminum and plastics etc 2.It can be widely used for automotive,injection mould,ironware mould and engrave mould industries. 3.Especially designed for engraving and moulding molds,eyeglasses,shoes,watches,panel,badge,brand, graphics and words of three-dimensional and outside surface's sleeking of large size.
FEATURES AT A GLANCE
COMMODITY&DESCRIPTION UNIT price QTY TOTAL Machine picture for reference Model SM0404-1         #Working area:400*400*150mm #spindle:3.0kw         #cooling system: water cooling #table moving         #Table frame: heavy duty frame,all iron cast #TBI linear square rail guide from Taiwan #Taiwan TBI ball screw  # Driving system: Stepper #inverter:Fuling       #control system :DSP #Tool sensor          #Artcam software    #Tool Box Machine comes with every part, you could use machine directly after machine arrival 1SET

Right elevation
Left elevation
Front elevation

Features of cnc moulding machine

1.The machine tools adopt the resin sand of high-standard stress relieving cast iron.
2.Thewhole body is gantry frame structure.
3.The linear lead rail of 3-axis may match x-axis.
4.The velocity of movement is fast andthe reaction is sensitive.
5.Equipping with the delicated system of high speed engrave moulding machine and high speed constant
power electric spindle.This makes high precision of processing and good smoothness.
6.Geometric precision and motion precision all proceeded strict laser detect and ball sensing instrument of searching circle detect to guarantee the quality of machine tools.
7.The machine adopts high precision ball screws of Taiwan,straight line rolling lead rail,locking screw nuts,importation twin axletrees and coupler.The retentivity is good.
8.The reaction is sensitive with big torque force of drive motor.
9.It is fit for processing rough,refined and high speed machining.
PRODUCT SPECIFICATIONS
No Description Parameter Option 1 X,Y,Z Working Area 400*400*150mm(400mm) 600x600mm 2 Table size 450*450mm 650x650mm 3 X,Y,Z Working Area ±0.03/300mm 4 X,Y,Z reposition Accuracy ±0.02mm 5 Table Surface T-slot Extrusions 6 Frame Cast steel 7 X, Y Structure Ball Screw 8 Z Structure Taiwan HIWIN Rail Linear Bearings and Ball Screw 9 Spindle 3.0KW 4.5/5.5KW/ATC Spindle 10 Spindle speed 24000rpm 28000RPM 11 Max. Rapid Travel Rate 4500mm/min 12 Max. Working Speed 4000mm/min 13 Drive Motors Stepper Servo 14 Working Voltage AC220V/50HZ/60HZ AC380/50HZ/60HZ 15 Command Language Command HPGL,G code,u00*,mmg,plt 16 Operating System DSP   Weihong NK200 17 Interface USB 18 Flash Memory 128M( U Disk) 19 Collet ER16 ER25 20 X,Y Resolution <0.01mm 21 Software Compatibility ARTCAM 22 Running Environment Temperature: 0°C~45°C Relative humidity: 30%~75% 23 Packing Size 910X880X850mm for SM0404-1 1120X880X1050mm (SM0404-2) 24 Net weight 900kg for SM0404-1 1500kg for SM0404-2
PRODUCT CONFIGURATION
SALES AND SERVICE NETWORK
Successful Project
SIMILAR PRODUCTS
FAQ
-Q What is the payment terms? A:Western Union,Cash,T/T -Q How long is the delivery date?(After getting the deposit) A:
Delivery time is 5-7 working days for standard machine models,please confirm with us before payment. -Q How about the shipping
ways? A:By sea or by air -Q Is on site training is available ? A: Yes, we could provide training in our factory or at your
workshop after machine arrival. -Q Where is your factory located? How can I visit there? A:Jinan City, Shandong Province, China,
about 2hours train from Beijing and Shanghai. -Q Can I arrange sample for cutting test? A:Yes, always welcome. -Q How about your
laser machine package? A: Standard export wood package with free fumigation -Q How about the quality guarantee period? A:5 Years
for whole machine -Q How can you guarantee the production quality ? A:We have 15years experience of QC team; strictly quality
control system in our production process. -Q: How to install and run the machine? A: Our technician have installed the machine
before shipping. For some small parts installation, we will send detail training video, user’s manual along with the machine. 95%
customers can learn by themselves.


SERVICE

PRE - SALE SERVICE

Semi-A1. Free Sample Machining Service Send us your designed files, we will arrange free sample machining in our factory and make video to show you the process and result, or send samples to you to check the machining quality. 2. Machining Solution Design: According to customer’s requirements, we can design the unique solution that supports higher manufacturing efficiency and better machining quality for customer. 3. Custom and OEM Service The divisions and partnerships of SMARTECHC welcome both custom work and OEM customers. We have a broad range of capabilities and manufacturing strengths, which makes it possible for SMARTECHC to customize our existing products for OEM customers.utomatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

During sale Service

We would deal with all the production and shipping affairs,after everything is ready,we would tell you everything goes well here;

AFTER-SALE SERVICE

1.We will supply the CNC router machine with training video and user's manual in English for installing, operation, maintenance and troubleshooting, and shall give technical guide by Desktop remote, E-mail, Telephone, Mobile, Whatsapp, Skype, 24/7 online chat, and so on, when you meet some problem of installation, operation or adjusting. 2. You can come to our CNC router machine factory for training.We will offer professional guide. Direct and effective face-to-face training. Here we have assembled equipment, all sorts of tools and testing facility. Training Time: 3~5 days. 3. Our engineer will do a door-to-door instruction training service at your local site. We need your help to deal with the visa formality, prepaid traveling expenses and accommodation to us during the business trip and service period before their dispatch. It's better to arrange a translator for both of our engineers during the training period.

GUARANTEE AND WARRANTY

New CNC router machines sold by SMARTECH carry a 3-years warranty (fiber laser cutting machines carry a 5 years warranty) effective from the date of shipping. CNC machines sold through dealers must be registered with SMARTECH within 30 days of purchase to be covered by this warranty. We would send new parts or repair for you during warranty period.
