Five-axis four-link bridge cutting machine
Features
1.Intelligent five-axis bridge cutting is a full-featured five-axis processing equipment. It has a camera function for positioning and layout,automatic measurement of sheet thickness and tool size, and the machine head can rotate 360 degrees.
2.Cutting,edging, chamfering, digging and other multi-function integrated intelligent operating system is easy to learn,high-quality motor.high precision and fast speed.
3.Horizontal,vertical,arc,circular,any angle and shape cutting head can be freely moved and rotated.
In addition to cutting shapes,it can also cut materials for large plates,45-degree chamfering, opening pot holes,stove holes,and diagonal line cutting.
| Machine Model | 3216 |
| Processing size | 3200*1600mm |
| Spindle motor | High-quality domestically produced 11kW motor |
| Saw blade diameter | 350mm-450mm |
| Control System | Special system for domestic bridge cutting machine |
| Hydraulic platform | Workbench 0-80°flip |
| Drive motor | servo motor |
| transmission | 25High precision guide rail extra heavy duty flange slider |
| Reducer | Japan Shimpo high precision reducer |
| rack | 1.5M |
| infrared | Equipped with laser infrared probe to display cutting path |
| Lubrication system | Automatic lubrication system |
| Dimensions | 3050x5820x2300mm |
| Operating voltage | 380V/50hz |
| Maximum Working thickness | 80mm |
| A-axis | 0-45° ,pneumatic adjustment |
The machine head automatically flips ±360 degrees The machine head can move the plate, which is more convenient.
