Aluminium Cutting Engraving Machine CNC Router

Availability:



Inquire Add to Basket

Model:
SWS Series 1325 CNC Router(CE standard)
Brand:
SMARTECH
Code:
New Product 2020
Size:
2500x1300x200mm
Power:
380V
Machine Color:
blue

Product Description

Product Description

Optional parts you might be interested in. #Optional dust collector double bags (used for woodworking materials)#Optional rotary device (used for round materials,removable. )
You could use directly after received machine, no need to buy additional parts.

COMMODITY&DESCRIPTION

 SWS Series 1325 CNC Router(CE standard) Working area: 1300x2500mm Original HIWIN Rails imported from Taiwan. Helical rack pinion gear transmission(more stable) T-slot table water tank (Stainless steel type, not iron.) Auto Tool sensor NC Studio controller Best inverter (best in China) Original Lead Shine Stepper motor and drivers 860 3.7 KW Water-cooling especial spindle for hard materials Water pump for spindle cooling Artcam /JD paint Software Limit switches for all x,y,z axis 3 pieces cooling sprayers Whole set tools #Used for Aluminium,granite,marble,glass,wood etc 3 Years warranty(we would send new parts for free for any damages during warranty)

 Left view

 Right view

 Front view

Optional parts:

 Optional Dust Collector for woodworking(To keep a clean environment)                         Optional rotary which is removable

PARAMETERS

 NO. Description Parameter Optional 1 X,Y,Z Working Area 1300x2500x200mm 1325/1530/2030 etc 2 Table Size 1550×3000mm 3 X,Y,Z Traveling Positioning Accuracy ±0.03/300mm 4 X,Y,Z repositioning Positioning Accuracy ±0.05mm 5 Lathe Structure Steel Structure 6 X, Y Structure Gear Wheel Transmission, Shaft Linear Bearings 7 Z Structure Ball Screw, Shaft Linear Bearings 8 Max. Consume power 6.5 Kw 9 Max. Speed 0-32000mm/min 10 Max. Working Speed 0-20000mm/min 11 Spindle Power Motor 3.7 KW water-cooling spindle Bigger power 12 Spindle Speed 0-24000RPM 0-18000RPM 13 Working Mode Stepper Servo 14 Working Voltage AC220V/50/60Hz,1PH (Option: 380V,3PH) 15 Command G Code, *uoo, *mmg, *plt 16 Operating System        NC Studio  DSP 17 Interface USB 18 Flash Memory 512M 19 Collet ER25 20 X,Y Working Delicacy <0.01mm 21 Software Artcam software UCANCAM OR ARTCUT 22 Running circumstance Temperature: 0℃～45℃ Relative humidity: 30%～75% 23 Packing Size Integrated: 3100X2350X1570mm 24 Net Weight 1600KG 25 Gross Weight 1500KG Suitable Materials:Stone,Marble,Aluminium,Wood,Acrylic,MDF,plastic etc


Spare parts:

 Cutting tools 20 pcs Collet 4 pcs Clamp 8 pcs Water-cooling Pump(for water cooling spindle) 1 unit Spanner 2 pcs Brush 1 pcs Power Cord 1 pcs USB Cable 1 pcs CD 1 pcs Tool Box 1 pcs Controller 1 pcs

Machine working sample

Company Profile

FAQ
-Q What is the payment terms?
A:Western Union,Cash,T/T
-Q How long is the delivery date?(After getting the deposit)
A: Delivery time is 5-7 working days for standard machine models,please confirm with us before payment.
-Q How about the shipping ways? A:By sea or by air
-Q Is on site training is available ?
A: Yes, we could provide training in our factory or at your workshop after machine arrival.
-Q Where is your factory located? How can I visit there?
 A:Jinan City, Shandong Province, China, about 2hours train from Beijing and Shanghai.
-Q Can I arrange sample for cutting test?
A:Yes, always welcome.
-Q How about your laser machine package?
A: Standard export wood package with free fumigation
-Q How about the quality guarantee period?
A:5 Years for whole machine
-Q How can you guarantee the production quality ?
A:We have 15years experience of QC team; strictly quality control system in our production process.
-Q: How to install and run the machine?
A: Our technician have installed the machine before shipping. For some small parts installation, we will send detail training video, user’s manual along with the machine. 95% customers can learn by themselves
