Handheld Laser Welding Machine Precision Portable Welder for Aluminum and Metals

You are here: Home » Laser Machines » Laser Welding Machine » Handheld Laser Welding Machine Precision Portable Welder for Aluminum and Metals

Share to:

Handheld Laser Welding Machine Precision Portable Welder for Aluminum and Metals

Main Configuration:
Laser power:600w
Fiber length: 2M
working mode:pulse
Cooling method: air cooling

Availability:



Inquire Add to Basket

Brand:
SMARTECH

Product Description

Handheld Laser Welding Machine Precision Portable Welder for Aluminum and Metals

Main Configuration:

Laser power:600w

Fiber length: 2M

working mode:pulse

Cooling method: air cooling welding

materials:Carbon steel / Stainless steel / Galvanized sheet / Iron / Aluminum

Rated voltage:220v

Net dimensions/weight:390x192x269mm/13KG

General Information

Performance characteristics 1. Self-developed high-reliability light source achieves ultra-long lifespan. 2. Portable and easy to move. 3. High photoelectric efficiency >50%. 4. Air-cooled heat dissipation, usable in ambient temperatures of -20°C to 35°C. 5. Extremely simple operation mode, rotary knob parameter adjustment. 6. Stepless fan speed regulation, environmentally adaptive heat dissipation.

PRODUCT SPECIFICATIONS

Product model	S1D
Laser power	600w ((Peak power 1200W)
Fiber length	2M
working mode	pulse
Cooling method	air cooling
welding materials	Carbon steel / Stainless steel / Galvanized sheet / Iron / Aluminum
Welding thickness	0.2-2mm
working environment	-20°C~35°C
Rated voltage	220v
Rated power	50hz/60hz
Maximum power consumption	<2.5KW
Net dimensions/weight	390x192x269mm/13KG
Packaging dimensions/weight	540x310x380mm/16KG
Packaging	carton

Nitrogen or argon is generally used as the protective gas. The purity of the protective gas must meet 99.99%, and the input gas pressure must be greater than 0.2 MPa and less than 0.5 MPa.
