Availability: | |
---|---|
SP1530
SMARTECH CNC LASER
1500*3000mm/2000*3000mm
depends on your demands
AS YOUR PREFERENCE
Cheap CNC Plasma Machine features:
1.Reasonable and economical design:One machine with plasma and flame torch,if the cutting metal thickness less than 10mm,
plasma torch is the best choice,if cutting thickness more than 10mm,flame torch is the best choice.
2.High quality stepping motors and drives for portable cutting machine,servo motors and drives for table/gantry type machine.
3.Solenoid valve,power line even plugs are all strictly to guarantee product's quality.
4.CNC system is with high configuration and high performance.Starfire,Fangling and Start are options.
Fastcam design software an support AutoCAD etc.
CNC PLASMA CUTTER Applicable Industries:
Case shell of mechanical and electrical products processing,advertising signage,process decoration, black smith gardens, automobile, shipbuilding, electrical accessories cutting and processing ,welding industry etc.
CNC PLASMA Cutting Machine Applied material:
Iron plate,stainless steel plate,titanium plate,galvanized sheet, high speed steel,etc
· ARM9+FPGA hardware solution, Operation and Interface refresh at a faster rate; · 7 "color LCD screen, friendly interface, show rich, high contrast makes the interface shows more clearly; · Unique function of the starting point of knife, test plate, graphics gallery number up to 63, a rectangular file directly edge features; · Up to 40000 rows; · System can restoration easily by a button, Follow-up more save worry; · 12 basic functions of wireless control operation. · 256M program files storage space; · Technology and structure are reasonable, with full optical coupling isolation control, super plasma anti-interference ability; · Support both plasma and flame cutting, graphics gallery function, the cut hole or section is optional, to arbitrary rotation, correction processing of graphics and function of X, Y, mirror image, graphics array functions; · Delay, preheating, perforated process control, etc; · Plasma arcing detection, initial positioning, corner signal control function; · Change torch, perforated displacement, moving parts, torch can adjust as your wishes; · Auto protect memory when breakpoint and power down, trajectory can along the way back to the origin; · Slotting and inversion clearance compensation function; · Graphical display, real-time cutting trajectory moving show; · Self-diagnostic system IO state, facilitate inspection and troubleshooting; · Program files can be copied to USB drive from NC system; · Documents could show the Chinese name , easy to discriminate the content of document in storage; Specifications:Standard configuration is propane cutting nozzle if no special requirement. |
Type | SP1530 |
Power source | AC 220±10%V 50/60Hz 180W |
Cutting mode | O2/C3H8 or C2H2, Plasma available |
Effective cutting range(mm) | 1500×3000 |
Host L×W×H(mm) | 462×366×280 |
Track L×W×H(mm) | 3000×273×60 |
Track Holder Quantity | 2 |
Track Holder L×W×H(mm) | 500×80×40 |
Cutting speed(mm/min) | 50-2000(Max 4000 available) |
Cutting thickness(Flame)(mm) | 5-150 |
Cutting thickness(Plasma)(mm) | In term of customer's plasma power source |
Move precision | ±0.2mm/m |
Torch | Flame,electric height adjustment(±60mm) |
Host weight(Kg) | 21 |
Gas pressure(Mpa) | Max0.1 |
Oxygen pressure(Mpa) | Max0.7 |
Type of gas | Propane, Ethane |
