Smart F-Mini-P
SMARTECH
20W
AS YOUR PREFERENCE
NO | Model | Smart-F Series 10W/20W/30W /50W |
1 | Laser power | Fiber 20W |
2 | Working area | 110*110mm |
3 | Weight(Table model) | 5KG |
4 | Power | MAX |
5 | Laser / PC Connectivity | USB connection/Phone |
6 | Power supply | Taiwan mean well |
7 | Response time | 0.03ms |
8 | Frequency of pulse | 20-100KHz |
9 | Scanning Speed: | 0-10000mm/s |
10 | Marking speed | ≤10000mm/s |
11 | Spot size | ≤40 micron (F-theta 160) |
12 | Marking lines | 1-10 lines(in the marking area) |
13 | Energy per pulse (PRR = 20 kHz) | 0.95 mJ |
14 | Laser switching ON/off time | 180 μsec |
15 | Marking content | Text,pattern,date,bar code,etc |
16 | Operation system | Magical MM |
17 | Graphic format supported | bmp, jpg, gif, tga, png,tif,ai,dxf,dst,plt, PRN, PSD, TIFF and AI etc |
18 | Unit power | ≤1.2KW |
19 | Operation temperature | 5℃-40℃ |
20 | Continuous working time | ≥16h |
21 | Relative moisture | ≤ 90%,no fog |
22 | Supply Voltage | 220V/50Hz/10A /380V/110V All available |
23 | Packing size | 28x23x18 CM |
