3D Fiber Laser Engraving Machine Curved Surface and Dynamic Focusing
You are here: Home » CNC Laser Machine » Laser Marking Machine » Fiber Laser Marking Machine » 3D Fiber Laser Engraving Machine Curved Surface and Dynamic Focusing
Share to:

3D Fiber Laser Engraving Machine Curved Surface and Dynamic Focusing

  • SF3D-PRO Laser Marking Machine
  • SMARTECH
  • New Product 2020
  • 20W / 30W / 60W / 80W / 100W / 120W
  • white
Product Overview
COMMODITY&DESCRIPTION Model:SF3D-PRO Laser Marking Machine #Ce standard #Feeltek Galvanometer and Field lens..............................................................one set #Famous brand Original Lenovo computer.,...................................................one set       #Power supply Taiwan mean well.....................................................................one set #Original Raycus device,IF copy double refund(For deep engraving)..........one set #Latest original Lenmark software……...........................................................one set #Double red pointer for focusing ,not single ...................................................one set #Up down table & controlling cabinet easy to carry..............................…..…one set #Tools and tool box comes with machine..........................................................one set #Protective glasses for free................................................................................one set #Fast speed Galvo galvanometer......................................................................one set #Data connection…………………...............................................................…one set #Foot pedal.........................................................................................................one set #User manual #Famous brands Schneider Bulk electrical parts #Optional rotary for bottles/pens etc round materials.
FEATURES AT A GLANCE
SF3D-PRO Laser Marking Machine
*Specifications:                                                                                                                         SF Series Model Fiber laser type Pulse fiber laser 20W/30W/60W/80W/100W/120W Max Single pulse energy 1mj Pulse duration 2-350ns Laser beam quality M2 <1.8 Frequency 20-1000khz Wavelength 1064nm Marking Area 110mm×110mm(optional) Spot size 27.5μm Max position speed 8μrad Min. linear width 0.01mm Min. Character size: 0.2mm Repetition Accuracy 0.05mm Control program Genuine EZCAD /FEELTEK control system Compatible with win7/8/10 Graphic format supported Jpg,Bmp,dxf,plt working voltage: AC220V 50HZ /AC110V 60HZ Cooling type Air cooling Operating parameter 0-40℃ Power consumption <=500w Packing size 98*83*142cm Gross weight 130kg
Optional part:(For some special working demands.) @1.Auto feeding system----Improve working efficiency(used for mass production,such as production dates/bottle caps’ numbers marking on packages etc For high efficiency demands)
@2.Rotary device for option  extra..…one set Included in the price offer √ (Used For round materials’ processing.such as:glasses,bottles,rings,pens etc)
@3.Aufo focus up down system--no need to measure distance by hands wheels------  (Upgrade from manual into automatic distance adjustment)
@4.Optional sliding X,Y moving table Pens rotating table (Especially for pens’ marking --You need this if you need a big demands on pens marking,otherwise the option 2.rotary device is ok for pens marking.)
@5.CCD camera for irregular materials, auto
registration function.  Recognize marking position automatically
@6.Change into 3D F20 for fastest deep engraving.(speed is faster than F10,could mark maximum 600x600mm working size)--If you have plenty budget and need big size marking, you could select this option  If you need a colorful marking on ss,sometimes needs deep engraving, you could select the SMARTECH JPT .(×)
If you only needs deep engraving on metal, no need colorful marking,then you could select JPT LP series.(?)
If you need to process on curve materials, you need the 3D laser.(√)
If you no have special requirements on the processing,just need to write the logos/text/images marking,then laser with raycus is ok .(√)
First layer is film,second layer is protective strong foam,third layer is Strong wooden case 870*770*1250mm (Table type)Gross weight is:130KG (Table type) Within 3 -7 working days after get deposit 30% T/T in advance, 70% before delivery 3 years (replace parts during warranty(no human reason)) 8-10 years (If work 10 hours per day) Could provide CO/CE/SASO/CIQ/Invoice etc Certificates for customs clearance
Right elevation
Left elevation
Front elevation
PRODUCT SPECIFICATIONS
Support the import of kinds of vector files and bitmap files. Support network port, serial port data reading, can facilitate automatic production line data interaction. Self-developed software, support further development. Optimization for application, open interface, can be customized to requirements. Support multi correction methods: fast and high precision correction on high precision ideal platform and free adjustment of each position focal point under the non-ideal plane, and finally achieve full format focus consistency. Provide production line marking, visual positioning marking, automation marking, and other solutions to meet the diverse needs of the customer. Support 3D application, support importing of STL model,self-developed model, etc. Support 3D data editing rapid realization of 3D surface marking, relief processing. Support expansion of 3D scanning requirement, it can realize the rapid localization and reverse processing of 3D work pieces, and the rapid marking of work pieces can be realized without the work piece model Packing list:  Item Name QUANTITY Machine Fiber laser marking machine  20W/30W/60W/80W/100W/120W with dynamic focus 1set Standard accessories 1 Focus ruler   1pcs 2 English user manual 1pcs 3 USB flash drive for program quick set up 1pcs 4 CD with EZCAD /FEELTEK control program 1pcs 5 Foot  touch switch 1pcs 6. inner hexagon wrench 1pcs 7. Power Cable 1pcs * Applications: Both for metal and non-metal materials              (working samples)
What is the difference between the 2D laser marking machine and 3D laser marking machine ?:1). 3D means Dynamic focusing, compare with ordinary 2D laser machine, 3D laser marking machine adopts different galvo head. Ordinary 2D scanning head only have two mirrors, but 3D scanning head have three mirrors. The third mirrors can move forward and backward. This is the key technology of 3D laser marking machine. 2). 3D laser marking machine outstanding functions are deep engraving, relief engraving and curve metal marking. 3). When 2D laser need to mark curve surface, it should be added one rotary fixture. However,3D laser marking machine can mark curve metal directly. Higher speed and higher precision. Mostly, easy to operation. 4). 3D laser marking machine is coming with 3D galvanometer head and 3D software. Other parts almost the same as 2D laser marking machine. 5). control card, lens and software is different 6)2D Fiber Laser Marking Systems.The 2-axis deflection units can be used to deflect a laser beam in X and Y directions. This produces a two-dimensional area allowing a laser to be directed at any position. This area is known as the “marking field” as shown in the diagram. Deflection is performed by two mirrors, each of which is moved by a galvanometer scanner. The deflection unit has a beam input, into which the laser beam is fed, and a beam output, through which a laser beam is emitted from the unit after deflection. 3D Fiber Laser Marking Systems In a 3-axis sub module the laser beam first enters a moving lens – the Linear-Translator-Module. A moving lens diverges the beam rapidly before it passes one or two focusing lenses. Then the beam hits a deflection unit that directs the laser towards any x-y position inside the marking field. *Application:                                                                                                                           1.Aluminium sheet stripped surface: No deformation, fine marking, color marking. 2.Metal depth marking. 3.Stainless steel color marking: marking different colors by setting the parameters. 4.PCB, ABS, Plastic without yellow color. 5.Light transmission paint keyboard: easy to make it previous to light. 6. Electronic, semiconductor components, ITO precision machining: the pulse can be adjusted to get best facula, and make the power balance 7.color marking and black marking on stainless steel. 8.Black marking and deep marking on nonferrous metal,like copper,alumina,aluminum. 9. Excellent marking effect on plastic or other sensitive material 10. Semi-conductor&electronics industry applications 11.Customade converyor belt for pen marking with much more high efficient work. Metal materials:stainless steel,aluminium,copper,silver, gold, carbon steel etc Non-metal materials :plastic,pvc,rubber,glass,stone,wood,feather,jewelry etc Advantages of SMARTECH laser comparing with normal fiber laser marking machine                                                            1.For short pulses and lower pulse energy, the material is e.g. heated less and the area of the heat affected zone is reduced. This results in more advantages and possibilities for laser marking metals and plastics: 2.No light leaking, safe marking 3.Less heat development during annealing markings on metal, which leads to a better corrosion behavior 4.Excellent beam quality, excellent processing performance 5.First pulse availability and quicker pulse response speed, good choice for highly precise & fine marking 6.More homogeneous and sometimes higher-contrast markings on some plastics 7.The advantages of the conventional fiber laser sources remain unchanged: 8.maintenance-free 9.long service life 10. 1ns ~ 250ns wide adjustable pulse width, wider application range of material 11.Wide repetition rate for diverse application12.High output power, high optical quality and compact size 13.Cleaner mark edges and faster marking speeds 14.Reliability and a lower cost of ownership 15.Plus, you’ll get the very best in efficiency. Fiber lasers are up to ten times more efficient than traditional YAG laser systems, and they use little to no energy in standby mode. Lenmark software:                                                                                                       Large field marking,3D surface marking, engraving,3D printing.Support customized development Software characteristicsLarge field marking,3D surface marking, engraving,3D printing.Support customized development - Support the import of kinds of vector files and bitmap files. - Support network port, serial port data reading, can facilitate automatic production line data interfaction. - Self-developed software, support further development. Optimization for application, open interface, can be customized to requirements. - Support multi correction methods: fast and high precision correction on high precision ideal platform and free adjustment of each position focal point under the non-ideal plane, and finally achieve full format focus consistency. - Provide production line marking, visual positioning marking,automation marking,other solutions to meet the diverse needs of the customer. - Support 3D application, support importing of STL model,self-developed model, etc. Support 3D data editing rapid realization of 3D surface marking, relief processing. - Support expansion of 3D scanning requirement, it can realize the rapid localization and reverse processing of 3D workpieces, and the rapid marking of workpieces can be realized without the workpiece model. Dual-scan head markingThe unique FEELTEK dual dynamic focus system, independently distributes the light source and processing parameters of the two systems through one set of software control. The motion coordinates of the two systems coincide completely in the processing space.It can be used in the application scenarios of laser heat treatment, additive manufacturing which require different light sources to act on the workpiece in order to meet the requirements of processing technology and efficiency. The customizable system API interfaceLenMark provides a rich API interface for supporting the user to realize the secondary development, including the control card API and the software API, which can meet the needs of the users from the development of hardware-based control to the application-level-based process development. Path optimization for real-time previewingBy implementing the preview function, users can adjust the order of marking the path to meet the needs of industrial field efficiency and process to the greatest extent.
PRODUCT CONFIGURATION
Successful Project
Features:1. Marks on curved tilted, multi-level surfaces 2. The most speedy industrial laser marker on the market 3. Withstands the most demanding environments 4. Provides high definition and permanent identifications 5. High precision, all axis moving synchronously 6. Laser is Pulsed fiber with excellent beam quality 7. Able to make markings on metal at high temperatures Threfore, 3D dynamic fousing system changes laser focal lengths and its laser beam positon is much better for perfect marking effects.The machine can applied in both flat marking and curve surface marking. It is one of the best technology in the industry. But we can use the 3D marking machine on sculptured surface. However, 3D laser marking machine is applicable for all types of metals and nonmetal materials. But laser marking on 3D surface. 3D laser marking machine is widely used in mobile manufacturing, cubic circuits, medical equipments, moulds, 3C electronics, auto parts, electronic communication, etc. We can apply world’s best German IPG fiber laser / Raycus or JPT power source in 3D laser marking machine.
