English
 |
SS1530-4
SMARTECH
1500x3000/2000x3000mm/1300x2500mm
3/4.5/5.5/6/9kw
as your preference
Multi Heads Granite Marble Stone Engraving CNC Router
CNC Router For marble specifications
NO. | Description | Parameter | Optional |
1 | X,Y,Z Working Area | 1500x3000x400mm | 1325/2030/2040 etc |
2 | Table Size | 2250×3800mm | |
3 | X,Y,Z Traveling Positioning Accuracy | ±0.03/300mm | |
4 | X,Y,Z repositioning Positioning Accuracy | ±0.05mm | |
5 | Lathe Structure | Steel Structure | |
6 | X, Y Structure | Gear Wheel Transmission, Shaft Linear Bearings | |
7 | Z Structure | Ball Screw, Shaft Linear Bearings | |
8 | Max. Consume power | 6 Kw(not include spindle) | |
9 | Max. Speed | 0-32000mm/min | |
10 | Max. Working Speed | 0-20000mm/min | |
11 | Spindle Power Motor | 3.0 KW *4 heads | 5.5KW |
12 | Spindle Speed | 0-24000RPM | 0-18000RPM |
13 | Working Mode | Stepper | Servo |
14 | Working Voltage | AC220V/50/60Hz,1PH
| (Option: 380V,3PH) |
15 | Command | G Code, *uoo, *mmg, *plt | |
16 | Operating System | DSP | NC Studio with computer |
17 | Interface | USB | |
18 | Flash Memory | 8GB | |
19 | Collet | ER25 | |
20 | X,Y Working Delicacy | <0.01mm | |
21 | Software | Artcam software | |
22 | Running circumstance | Temperature: 0℃～45℃ | |
23 | Packing Size | Integrated: 4200X2250X1870mm | |
24 | Net Weight | 3300KG | |
25 | Gross Weight | 3500KG |
CNC Router For marble stone granite Engraving samples
Beautiful design
Multi cooling nozzle
Auto feeding roller especially for heavy materials
Lubricating oil system
Single head marble cnc router for options
FAQ
-Q What is the payment terms? A:Western Union,Cash,T/T
-Q How long is the delivery date?(After getting the deposit) A: Delivery time is 5-7 working days for standard machine models,please confirm with us before payment.-Q How about the shipping ways? A:By sea or by air
-Q Is on site training is available ? A: Yes, we could provide training in our factory or at your
workshop after machine arrival. -Q Where is your factory located? How can I visit there? A:Jinan City, Shandong Province, China, about 2hours train from Beijing and Shanghai.
-Q Can I arrange sample for cutting test? a
A:Yes, always welcome.
-Q How about your laser machine package? A: Standard export wood package with free fumigation
-Q How about the quality guarantee period? A:5 Years for whole machine -Q How can you guarantee the production quality ? A:We have 15years experience of QC team; strictly quality control system in our production process. -Q: How to install and run the machine?A: Our technician have installed the machine before shipping. For some small parts installation, we will send detail training video, user’s manual along with the machine. 95% customers can learn by themselves.
Contact us for more information ~~
