SPR Series
SMARTECH CNC LASER
2000*6000mm / Customized
45A/65A/85A/105A/120A/160A/200A
AS YOUR PREFERENCE
CNC Plasma Cutter with Rotary device for round metal cutting
CNC PLASMA CUTTER
Working area:2000x6000mm(8'*20')
---Control system:Starfire + ARC torch height control system.
---Hypertherm plasma power supply/Chinese power supply
---Gear-wheel transmission
----Square rail not round rail.
---Original TBI rails not steel plate.
----FASTCAM Control Software
------Leadshine stepper motor and drivers
----With adjustable up-down device.
---collision avoidance systerm
--------customized size rotary device for pipes/tubes cutting demands.
Our customers put their Cutting Systems CNC pipe cutting machines to the test each and every day. We serve clients from a variety of industries including:
Amusement ride manufacturing
Storage tank fabricating
Energy facilities
Fabrication
Steel fabrication
Process piping
And more
Parameters of CNC Plasma Cutting Machine
Description | SPR SERIES Plasma cutter | Option |
Effective cutting area(X*Y) | 2000*6000mm(8’*20’/CUSTOMIZED) | CUSTOMIZED |
Working material | Iron, steel, sheets, galvanized sheets, titanium plates etc | |
Cutting thickness | According to materials | |
Plasma power | Hypertherm | Chinese |
Drive Mode | Bilateral-side | |
CNC system | Beijing START | Beijing Starfire |
Plasma cutting speed | 50-6500 mm/min | |
Cutting torch lifting distance | 150mm | |
Speed setting error | ≤±5% | |
Torch height controller accuracy | ≤±1.0mm | |
Longitudinal line accuracy | ±0.2mm/10m | |
Motor and drivers | Stepper | SERVO |
Gearbox | Cast Iron (Better than welded) | |
Drive Method | Rack and square rails for Y axis | |
Rail Brand | Taiwan HIWN | PMI |
Moving Precision | 0.01mm per step | |
Power Source | 50 Hz or 60HZ 380V | 220V/110V |
Height controller(plasma) | PHC330-Arc voltage height controller for plasma cutting | |
Idling Cutting speed | 0-12000mm/min | |
Input voltage | 3 phase 380V | |
Files transfer | USB interface | |
Arc | Untouched arc striking | |
General machine accuracy | ±0.5mm |
At SMARTECH Cutting Systems, we know your jobs demand accuracy with minimal downtime. Our rugged CNC plasma pipe cutting machines are built for durability and strength, handling the toughest of jobs. Whether you need a machine to run 8 hours a day or 24/7, we have a pipe cutting machine to fit your high demands.
