Cheap 1325 Wood Cnc Router China Affordable Price

1325 cnc router working area is 1300x2500mm about 4x8 feet. The 1325 cnc router model is the most used model for many industries,such as decration industry,art craft industry,woodworking industry etc.How to select a right model for your business ? Most impartant factor is your maximum materials size and application industries.
Availability:
  • SW1325

  • SMARTECH

  • 1300x2500mm

  • 3.0kw/3.5kw/4.5kw/6kw/7.5kw

  • as your preference

Cheap 1325 Wood Cnc Router China Affordable Price Applications:

1) Mould: wood,wax,wood,gypsum,foams,wax.
2) Furniture: wooden doors, cabinets, plate, office and wood furniture, tables, chair, doors and windows.
3) The wood products: voice box,game cabinets,computer tables,sewing machines table,instruments.
4) Plate processing: insulation part,plastic chemical components, PCB, inner body of car, bowling tracks, stairs, anti bate board, epoxy resin, ABS, PP, PE and other carbon mixed compounds.
5) Decorate industry:Acrylic,PVC,MDF, artificial stone,organic glass,plastic and soft metals such as copper, aluminum plate engraving and milling process.

NO.

Description

Parameter

1

X,Y,Z Working Area

1300x2500x200mm

2

Table Size

1800×3000mm

3

X,Y,Z Traveling Positioning Accurate

±0.03/300mm

4

X,Y,Z Repositioning Accurate

±0.05mm


Locating precision

Locating precision

5

Lathe Structure

Cast Iron Structure

6

X, Y Structure

Gear Wheel Transmission,Shaft Linear Bearings

7

Z Structure

Ball Screw, shaft Linear Bearing

8

Max. Consume power

6.5Kw

9

Max.Speed

0-60000mm/min

10

Max. Working Speed

0-40000mm/min

11

Spindle Power Motor

 3.2 kw spindle

12

Spindle Speed

0-24000 RPM/0-18000 RPM

13

Motor

Stepper

14

Working Voltage

AC220V/50/60Hz,1PH (Option: 380V,3PH) or as your factory voltage

15

Command

G Code, *uoo, *mmg, *plt *.nc

16

Operating System

 nc studio

17

Interface

USB/PC

18

System support

WINDOWS XP/ windows 7/8/10

19

Min shaping character

Character:2x2mm,letter:1x1mm

20

Flash Memory

525MB

21

Collet

ER25,ER20

22

X,Y Working Delicate

<0.01mm

23

Software

Artcam software, UCANCAM ,Type3 and other CAD or CAM software

24

Running Circumstance

Temperature: 0℃~45℃
Relative humidity: 30%~75%

25

Packing Size

3200X2250X1700mm

26

Net Weight

900KG

27

Gross Weight

1100KG

acrylic engravingcnc router working samplealuminium pvc plate cuttingplywood board cuttingDecorative screen hollowLeather car matcnc router 1325cnc router loading
