Nesting ATC CNC Router With Auto Loading Unloading System

Auto feeding system comes with automatic loading unloading table which could load unload materials automatically instead of labor hands.which could save labor cost and improve efficiency greatly.nesting cnc router could be amounted by hsd auto tools changer spindle and four heads pnuematic spindles. this nesting cnc router with loading unloading system is mainly used for woodworking fields.such as cabinets,closets,furnitures etc production.

  • SWO1325 ATC
  • SMARTECH
  • as your preference

Nesting Auto Feeding CNC Router For Furniture Production Line

The SMARTECH panel furniture solution is a high-speed, automatic load/unload, heavy-duty CNC routing system for nested based feed through machining. It is a multi function cnc center for panal furniture cutting and drilling, instead of the traditional labor production process. It is used in nested based production of cabinets, closets and custom furniture.

ATC CNC Router For Furniture Production Features:

1. Automatical feeding
Suck the board to the next process automatically.
2. Automatical CNC processing
With automatical tool changer , can cutting, milling, drilling, engraving, etc.automatically.
3. Automatical discharge
After process, the boards are discharged automatically.

4.Save Thousands of labor cost.

5.Save materials,and reduce materials' waste.

Suitable Industry of nesting cnc router:
Office furniture, wood cabinet furniture and furniture customized etc. Automation is considered the fastest route to improving productivity and profitability in the manufacturing sector.
Nesting ATC CNC Router For Furniture Production Line Parameters:

No.

Configurations

Qty

Options













Equipment

SWO1325-4 ATC With Auto loading unloading system













Standard

1 set



SWO1530-4/SWO2030-4

Machine Body: Steel Structure.Thickening of lathe bed,With high temperature heat treatment, high precision, long service life


Working area:1300*2500*250mm




Package size:3150*2250*2300 mm


Weight:2600kg




HIWIN Rail for 3 axis   Helical tooth rack


Original TBI Ball screw


Speed:Idling 60-80m/min  Working speed:20m/min


Rail:Y axis 2.5 X,Z Axis 2.0(Y axis 3.0 X 2.5,Z Axis 2.0 or X,Y 2.5,Z 2.0 For options)




screw rack












Main parts

Servo 2206

4 sets

Yaskawa servo

Fuling inverter



1 set


Original ShanLong controller

1 set


Standard huge computer control box



1 set


 Spindle power 4*6KW/380VCould be customized according to your request.





3 sets

ATC Spindle

Spindle:air cooling (easier operation,especially for woodworking)

standard



Electricity parts: Original Schneider


Table

Vacuum pump ---Ball valves control



standard


Pop-pin on table for positioning














Ancillary attachment



Standard tool sensor,Manual lubricating system



1 set


Dust collector double bags(With Dust collection pipeline switch)



1 set


Free-oil pump 5.5KW/380V



1 set


Standard woodworking tools and tool box



1 set


level adjustment tools

6 sets


Software:Artcam or Artcut or type3 for option



1 set


Electricity parts: Original Schneider



standard


Collet 6 2 pieces;Collet 4 2 pieces;Spanners 2 sets

6 sets


Voltage

380V/220V 1 phase/3 phase

standard


Package

1.Fixed film--->2.Thick protective film--->3.Standard Plywood Carton

standard




Application samples by smartech cnc router

furniture production linecnc router for furniture production line
