Factory Supply Cnc Router Engraving Machine Cnc 1325 1530 Router 4 Axis 220v Single Phase Wood Router Machine Price

Availability:


Inquire Add to Basket

Model: CNC Router
Brand: SMARTECH
Code: New Product 2021
Size: 3100 * 1950 * 1850mm
Power: 220V / 380V 50 / 60HZ,380V / 220V 50HZ
Machine Color: as your preference

Product Description

Product Overview

2020 Best Price 2040 CNC Router Machine For Woodworking/Advertising/Interior

 SW2040-A Model cnc router #Working area:2000*4000*200MM #6KW self cooling spindle #7.5KW Inverter #Taiwan TBI Ball Screw, Taiwan HIWIN/PMI/ABBA Linear Square Rail(famous) #nc studio /DSP Controller #Artcam software #Vacuum table with vacuum pump #Stepper motor and driver yako 2811 #Temperature thermometer to detect spindle temperature timely. #lubrication system (lubricate oil for machine maintain,standard is one) #leakage protector(protect operators’ safety) #Tools and tool box #Leveling feet #Emergency Stop button for motor #Press roller for free(help materials not move during processing and assure a good precision) #Dust collector for free ( to keep a clean workshop and protect guide rails) Machine color could be customized Optional part you might need select to upgrade your machine: @Rotary Device (It can work with cylindrical object.) Machine comes with full set parts,no need to buy additional parts.could be used directly after arrival Warranty : 3 years; 24 Hours Lifetime after sale service for free 4,999 USD FOB Qingdao port 1SET Delivery time : 7-10 working days after order is confirmed.


FEATURES AT A GLANCE

  1. Features @1.Original HQD air cooling spindle 6 Kw ,very powerful and top quality @2.Leadshine stepper motor or servo system, powerful,precision and durable @3.Heavy duty frame and gantry @4.rapid running speed: two axes are rack gear, fast speed and high efficiency, The highest speed is 45mpm. @5.Intelligent control: adopting nc studio control system.It is very easy to master,especially for the beginners. @6.China best brand inverter @7.Temperature monitor could show the spindle temperature,huminity and timing clock help take rest for machine more friendly. @8.Original imported rails,not copy ones could assure the machine precision and longer life span. @9.Double layers pvc table not single layer,keep machine more stable. @10.Big computer control box which could put computer main board and screen beside the machine more conveniently @11.Press roller on the machine table could fix materials on table more tightly without any move during works. @12.Big Control Cabinet for nc studio control system which is friendly for computer and keyboard. 2. Parameters Description Parameter Optional parts Model 2040 Woodworking Machines X,Y,Z Working Area 2000*4000*200mm Bigger or smaller(customized) Traveling Positioning Accuracy ±0.03/300mm(X,Y,Z Axis) Table Surface Vacuum Table 6 zones or as your demands. Combination of T-slot&Vacuum Table Frame New type thicker and bigger heavy duty frame gantry X, Y Structure Helical Rack gear, Taiwan PMI Linear Square Rail Z Structure Taiwan TBI Ball Screw, Taiwan PMI Linear Square Rail Spindle 6kw HQD Italy HSD air cooling spindle Max.Speed 0-60000mm/min Max. Working Speed 0-40000mm/min Inverter 7.5kw Chinese best Inverter Taiwan Delta Lubrication system Manual lubrication system Working Voltage AC380V, 3Ph, 50Hz 220V/Customized according to your workshop voltage Command G Code, *uoo, *mmg, *plt Operating System nc studio System mach3 /DSP Interface USB Flash Memory 512MB (For dsp only) +8 MB Collet ER25,ER32 Running Circumstance Temperature: 0℃～45℃ Relative humidity: 30%～75% Packing Size Integrated: 4600x2250X1950mm Separated: 4600X2250X1080mm Net Weight 2500KG Gross Weight 2600KG


 Right elevation

 Left elevation

 Front elevation

PRODUCT SPECIFICATIONS

 Cutting tools 20 pcs Collet 4 pcs Clamp(for t slot table or combination of t slot and vacuum table) 8 pcs Water-cooling Pump(for water cooling spindle) 1 unit Spanner 2 pcs Brush 1 pcs Power Cord 1 pcs USB Cable 1 pcs Tool Box 1 pcs Controller 1 pcs Lubrating system 1 pc Tool sensor 1 pc
